Learning 3D programs – Tinkercad

jack11
Blog post from Library as Makerspace

It’s time to move on from printing uploaded files to creating 3D objects to print. Tinkercad is the perfect site to begin. (I learned about tickercad from our NCKL Youth Consultant who pointed me to the blog: LIBRARY As MAKERSPACE!) With Halloween coming, a Jack-0-lantern sounded appropriate.

jack1
Uploaded the pumpkin

I found the program to be challenging – probably because I’m not one to go through the tutorials – just like to jump right in!  I did however refer back to the blog several times. Uploading a pumpkin 3D file was the easy part. Carving out the inside and the face was challenging! I learned how to do sizing, grouping and adding workspaces.

jack12
Creating the holes – used a sphere to carve out the inside.



jack4
Front view on Tinkercad
jack3
Side view showing the workspace that allowed adding the shapes for the face.

After using the Tinkercad program to “carve out” the pumpkin and the face. I uploaded the file to the flashprint program adding the supports and base.

jack6
Jack-o-Lantern uploaded into the 3D printer software.
jack7
Printing the raft and a few supports

And now… it’s printing.

The Jack-o-lantern is facing the back of the printer.

jack13
The mouth cut out.
jack15
Triangles for eyes

jack14

jack16
Hexagon inside for supports – probably should have made the sphere larger.
jack17
A problem is developing
jack18
Must need more supports on the inside.
jack19
Looks good from this angle
jack20
Not so great from the top

Live and Learn – another day!







The Lightsaber (Part 1)

Today was a no school day, so there was a lot of action at the library with over 40 patron visits!

The 3D Printer also ran constantly today. We are excited to see a student attempt a multi piece project – the Lightsaber! The saber was printed in six files with sometimes up to three items printing at once. Isaac loaded and sized his project on his home computer, bringing the files in on a flash drive. After loading on to our program, I double checked the filament side (PLA) and added a raft to each piece. Originally, we planned to print the small pieces without the raft but were unsuccessful. If they are too small the filament doesn’t adhere to the bed which results in a jumbled mess.

14713689_1422993997714127_3819516648425134048_n

Here the small parts have been printed and we are watching the lightsaber’s handle print. This was the biggest file taking an hour and a half to print. The whole project took just over 3 hours for all six files.

14650671_1422994034380790_8833677481233998605_n

Isaac will be taking the pieces home to glue together and paint. You can see that he has removed some of the raft on the small pieces. He will be researching adhesive and paint options – check back to see the finished project!

Drop by and print a project of your own!



Trials and Triumphs of the 3D Printer: Part 3

Yesterday and today the 3D printer was finally behaving appropriately with the corrected settings and clean gears and nozzles.

A complete print of the minion was made from both sides with both filaments. PLA (Polylactic Acid) is is a biodegradable thermoplastic aliphatic polyester derived from renewable resources, such as corn starch. ABS (Acrylonitrile-Butadiene-Styrene) is an opaque thermoplastic polymer material made from the monomers Acrylonitrile, 1,3-Butadiene and Styrene. Strong and durable even at low temperatures, it offers good resistance to heat and chemicals and is easy to process.

The blue spool is PLA while the white spool is ABS.

Yesterday we printed with PLA with the left side. This blue minion took 2 hours and 45 minutes to print. PLA has a lower temperature setting than the ABS which was the main source of our problems.

completeminion1

completeminion2

completeminion3

completeminion6

Today was also a successful day with a complete print from the right side, the ABS filament. The white minion took 2 hours and 20 minutes to print but is a little smaller.

plaabsminions







3D Printer

The new 3D Printer arrived Thursday, Sept. 22. After set up we printed the test sample:

3d 3d1 3d2

Next a Minion was attempted. Because the Minion moved on the print bed, the print failed. The supports were also configured incorrectly.

m1 m2

Pistol Pete, a workshop project chosen by a participant, made it through a complete print. The default dimensions need to be adjusted as it is very fragile. So fragile, that it was nearly impossible to remove the support base.

pistolpete

Next returning to the blue filament. An attempt at a Mocking Jay ornament also chosen during the workshop, resulted in the realization that the blue feed/nozzle is in trouble. Eventually it there was no filament extruding.

trouble

Fearlessly, the nozzles and gear feed mechanism was disassembled. The blue filament should go straight through the mechanism, not curl around the gear.

trouble2   trouble3

Everything was put back together. Then a second attempt was made on the Mocking Jay.

mjn

mjn1

Then there was a “network error”!

mjn2

Sometime was spent discussing the issues with the tech. consultant Mr. Tang.

This resulted in a complete print!!! WHEW! (Sept. 29, 2016)

mjc

mjc1

mjc2

An attempt was made to use the right extruder. This resulted in:

mt

A mess…. it is probably blocked again…
